Intel® SKM Box Computer

ISKM-CFL3-Q370

Intel® Smart KIOSK Module Box system with Intel® 8th Gen Processor
  • Intel® 8th Gen Core i7/i5/i3 Processor
  • 2 x DDR4 SO-DIMMs up to 32GB
  • HDMI/DP , 1 x LAN, 2x USB 3.1 , 2x USB 3.0 ,6 x USB 2.0, 7 x COM, 1 x DIO, 1 x AUDIO
  • 2 x Mini PCIe (1 x w/ uSIM), 1 x M.2 M-Key 2280(SSD socket 3), 1 x SATA III
  • Power input : DC-IN Jack 12Vdc or 19Vdc ~24Vdc
ISKM-CFL3-Q370 is a high-performance interactive kiosk solution based on Intel's Smart Kiosk Module. The heart of the Smart KIOSK Box Computer includes an Intel 8th Gen. Core i7/i5/i3 microprocessor. Graphics functions are handled by an Intel HD Gen. 9-LP graphics processing unit (GPU). The system also features two DDR4 SO-DIMMs, for up to 32 Gbytes of memory, and a host of interfaces, including HDMI, DP, USB, Serial, UART, and M.2.

The scalable modular approach and simple connection also result in easier servicing, maintaining, upgrading, and integrating new technologies into kiosks, while reducing costs as well as the total cost of ownership. It is also designed to support workload accelerators for analytics and artificial intelligence (AI) in the future as the demand for those applications grows. Note that backward compatibility is included for Intel's Smart Display Module Small (SDM-S) and Smart Display Module Large (SDM-L) form factors that are common for integrated displays.
Model name ISKM-CFL3-Q370
Construction Metal
Standard color Black
CPU Intel® 8th Gen Core™ i7/i5/i3/Pentium®/ Celeron®(LGA1151) Processor(max. TDP 65W)
Chipset Intel® Q370 PCH
BIOS AMI SPI Flash ROM
System memory 2 x 260-pin DDR4 2666MHz SDRAM; max. up to 32GB
Graphic Intel® HD Gen. 9-LP Graphics
Watchdog Timer Interval: Programmable 1 ~ 255 sec. Output: System reset
System I/O
USB 2 x USB 3.0, 2 x USB 3.1, 6 x USB 2.0
COM 7 x COM
LAN 1
Display 1 x HDMI, 1 x DP
Audio Mic-in, Line-out
PS/2 N/A
Others 2 x I2C, 1x GPIO
Storage Support
HDD 1 x 2.5" HDD
CF N/A
CFast N/A
M.2 1 x M.2 M-key 2280(SSD) slot
System
Indicators 1 x Power LED
Controls 1 x Power on switch
Power
Power supply DC-IN Jack 12Vdc or 19Vdc~ 24Vdc
Environment
Operating Temperature 0°C ~ 40°C
Storage Temperature -20°C ~ 60°C
Relative Humidity 0% ~ 90% (non-condensing)
Mechanical
Mounting Desktop/Wall mount
Weight 2.9 kg
Dimensions (W)x(D)x(H)mm 239mm(W) x 196mm(D) x 90mm(H)
